EV powertrain
for 2-wheeler,3-wheeler and low speed 4 wheeler
Battery pack customize design.
Voltage range 24V to 400V
We have matched charger for the battery. DC Fast Charger available
Tell us your concept, we design, prototype and production for you. Can be electrical, PCB or mechanical fabrication.
RDM Inverter
72100A:(Encoder/hall)
Suitable motor power:1~2kw
72200A:(Encoder/hall)
Suitable motor power 3~5kw
72500A:(Encoder/hall)
Suitable motor power 5~7.5kw
Features:
IP67(1 Meter under water)
Benefits: Customizable riding mode,
Electronic regenerative brake. Anti-Theft
Permanent magnet synchronous motor (PMSM)
Power range:2kw,3kw,5kw,7.5kw,10kw,15kw,20kw
Cooling: Air cool, S9
Efficiency: >94%
Limited temperature:98°C
Encoder: Hall Sensor/RDM encoder
Benefits:
Direct drive with silence and better efficiency
PMSM with 4 level Gearbox
Power:
Rated 2kw, peak 4kw.
Rated Speed 6000rpm, peak 7000rpm.
First Gear:500N.m Torque
Rated 5kw, peak 15kw
Rated Speed 6000rpm, peak 8000rpm.
First Gear:1000N.m Torque(With RDM84500Controller)
Benefits: Good for heavy duty application
Customizable turn on LOGO
4.3Inch, 5Inch, 7Inch
Bluetooth connectivity
Link with your smart phone.
Display phone call, what's app message.
Google map navigation
Day and Night mode.
ECU fault display
Background color change with power mode
1080P on board camera
Plug and play solution.
2KW kits:
Typically produce 100CC petrol motorcycle power. 15N.m torque. and top speed can expect at 70 to 100km/h.
3kw kits:
Typically produce 150CC petrol motorcycle power. 20N.m torque. and top speed can expect at 70 to 150km/h.
5kw kits:
Typically produce 250CC petrol motorcycle power. 70N.m torque. and top speed can expect at 80 to 180km/h.
Specification
DC-DC Converter
Size:70*65*25mm
Input:30-94VDC
36W DC-DC
Output 12V 3A
120W DC-DC (Pre-Order)
Output 12V 10A
140W DC-DC (Pre-Order)
Output 14V 10A
Rated Power:1kw
Max Power: 2kw
Max Speed:90km/h
Max Torque:>50N.m.
Net Weight:80KG
Rated Power:2kw
Max Power: 6kw
Max Speed:105km/h
Max Torque:>500N.m.
Net Weight:108KG
Lithium Battery: 72V 50Ah(CATL)
Charging time: 1.5Hour
Rated Power:5kw
Max Power: 10kw
Max Speed:45km/h
Max Torque:>100N.m.
Net Weight:500KG
What is IP67 rated?
International standard that was developed by the International Electrical Commission (IEC 60529)
IP: Ingress Protection
6: Dust tight; dust cannot ingress
7: Secure when immersed in water up to 1m for 30 minutes
